Aggregates of different sizes are fed into separate bins for proper proportioning. Each bin has a variable speed drive motor to control the feed rate.
Cold Aggregate Four-bin Feeder
1
Acts as storage and heating for bitumen, available in sizes from 15 to 30 tons. Heated by a burner to achieve high thermal ratings and reduce emissions.
Bitumen Tank
2
Simple system with two firing rates: low and full. Easy to replace with no complex parts or electronic components.
Pressure Jet Oil Burner
3
The rotating drum dries aggregates in the first half and mixes them with bitumen in the second half. Parallel flow system ensures uniform mixing.
Drying & Mixing Unit
4
Features an electric power console, distribution switchboard, and fully automatic processes. Displays control parameters and allows auto/manual mode operation.
Control Cabin & Panel
5
VENTURI type wet dust collectors maintain environmental standards. Stainless steel nozzles provide clog-free operation for optimum cleaning efficiency.
Pollution Control Unit (Optional)
6
